The Infrared Emitter and Receiver are sim-ply plugged in, leveled and secured at eachlane.
Two conductor outputs for each Pinsettersimply quick-splice to the bowlers reset but-ton wires.ģ. Wall transformer plugs into 115 Volt out-let for power supply.Ģ. Simple Installation: ZOTs ET 2001 installsin three easy steps:ġ. That same few seconds will pay for ZOTs ET2001 Dual Lane Electronic Triggering sys-tem several times over in its first year, and,thereafter, the additional revenues, savingsand improved customer relations, translateinto clear, and measurable, increased profits. Youngsters, seniors, and bowlers usinglight balls especially in centers withbumper bowling frustrated, and wastingtime, either because theyre slow to react inpressing the reset button, or because theydont know what to do, when the machinefails to cycle. It only takes a few seconds a game to savethousands of dollars a year in lost linage,revenues, power consumption, andmachine wear and tear and to improvecustomer satisfaction levels. ZOTs ET 2001 Dual Lane ElectronicTriggering, for Brunswick Pinsetters, fea-tures the latest and most advancedinfrared technology available in the indus-try, to guarantee 100% PositiveTriggeringball after ball after ballyouknow it makes sense. Remote Trigger Ports: ZOTs ET 2001 can betriggered by external sources, e.g., scoringsystem remote switch.ĭiagnostic Indicator: ZOT has added an LEDsystem which indicates when an outputsignal is occurring.ĮT 2001 Dual Lane Electronic Triggering#400130 (115V/60Hz) #400036 (230V/50Hz)
Download Brunswick Pinsetter Manual A2 Pc#
Safety System: The ET 2001 has a built-inSafety System which prevents the machinefrom cycling if a person is in the area wherethe sensors are mounted.Īll Modular Design: All components pluginto the PC Board separately, making it pos-sible and easy to change parts, and trou-bleshoot. Infrared Technology: The ET 2001 featuresan Infrared Sensor source thats Solid StateDiode Rated for millions of hours ofdependable service. With more than adecade in the marketplace, this miniatureand ruggedly constructed sensor systemhas a proven track record of minimizingdamage by balls and pins and its not sen-sitive to vibration.Īlignment Indicator: ZOTs ET 2001 featuresan exclusive 4-unit LED system, that indi-cates when the sensors signal is strongest.The LEDs can be viewed from either the sen-sor area, or from the top of the pinsetter,without opening the cover.Ĭontrol Box Protection: ZOTs Dual LaneControl Box mounts on the back of themasking unit curtain wall, out of the way ofpotential damage by balls or pins.
Superior Sensor Design: The ET 2001retains the same sensor design as ZOTs sin-gle-lane Magic Eye. World Class PC Design: ZOTs new Micro-Processor technology simplifies the circuit,making the ET 2001 (Electronic Triggering)Dual Lane Ball Detector surprisingly cost-efficient. For Triggering Brunswick PinsettersAt last! The product that customers have been asking fora Pinsetter Triggering & Scanner Ball DetectorSystemcombined in ONE product.Triggering Improvements that Promote Bowling Features and Benefits
